Beskrivelse
-
- Output voltage at 1000 Hz, 5cm/sec. 4 mV –
-
- Frequency range at – 3dB 20-20.000 Hz
-
- Frequency response 20-20.000 Hz + 3 / – 1 dB
-
- Tracking ability at 315Hz at recommended tracking force 70 µm
-
- Compliance, dynamic, lateral 18 µm/mN
-
- Stylus type Spherical
-
- Stylus tip radius R 65 µm
-
- Tracking force range 1,6-2,0g (16-20 mN)
-
- Tracking force, recommended 1,8 g (18 mN)
-
- Tracking angle 20°
-
- Internal impedance, DC resistance 700 Ohm
-
- Internal inductance 300 mH
-
- Recommended load resistance 47 kOhm
-
- Recommended load capacitance 150-300 pF
-
- Cartridge colour, body/stylus Black/Grey
-
- Cartridge weight without screws 7,2 g
