Beskrivelse
- Output voltage at 1000 Hz, 5cm/sec. 4 mV –
- Frequency range at – 3dB 20-20.000 Hz
- Frequency response 20-20.000 Hz + 3 / – 1 dB
- Tracking ability at 315Hz at recommended tracking force 70 µm
- Compliance, dynamic, lateral 18 µm/mN
- Stylus type Spherical
- Stylus tip radius R 65 µm
- Tracking force range 1,6-2,0g (16-20 mN)
- Tracking force, recommended 1,8 g (18 mN)
- Tracking angle 20°
- Internal impedance, DC resistance 700 Ohm
- Internal inductance 300 mH
- Recommended load resistance 47 kOhm
- Recommended load capacitance 150-300 pF
- Cartridge colour, body/stylus Black/Grey
- Cartridge weight without screws 7,2 g
